Huayang PLC Screen SS Spot Welding Machine 60times/Min Stainless Steel

Huayang PLC Screen SS Spot Welding Machine 60times/Min Stainless Steel
Huayang PLC Screen SS Spot Welding Machine 60times/Min Stainless Steel

Large Image :  Huayang PLC Screen SS Spot Welding Machine 60times/Min Stainless Steel

Product Details:
Place of Origin: China
Brand Name: Huayang
Certification: CE
Model Number: R-DHW
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: 1.Machine will be covered with plastic film and fastened by steel wire in container. 2. Spare parts will be packed into carton box and fastened stable in container.
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 20 sets/month

Huayang PLC Screen SS Spot Welding Machine 60times/Min Stainless Steel

Description
Product Name: Automatic PLC Touch Screen Pneumatic Spot Welding Machine Applicable Industries: Building Material Shops, Manufacturing Plant, Farms, Home Using
Feature: Automatic Wire Feeding Rated Duty Cycle: 66%
Wire Diameter: 3.0-8.0mm Motor Power: 7.5KW
Rated Voltage: 380V -3 Phase 50Hz Or Design To Customer Welding Speed: 60 Times/minute
Line Wire Space: >=50mm Motor: 5.5
High Light:

PLC Screen SS Spot Welding Machine

,

Huayang SS Spot Welding Machine

,

60times/Min Stainless Steel spot welder

Automatic PLC Touch Screen Pneumatic Spot Welding Machine

1. Product description

Automatic PLC touch screen pneumatic spot welding machine is used for making panel wire mesh. The machine adopts synchronous control technology, control of welding and welding time are controlled by the digital programming system, the input panel for touch screen or keys, operating more intelligent, and has one pressed, split welding characteristics, welding power is driven by electric, the step motor feeding hopper, brake motor to drive the car for wire feeding, the stepper motor to drive the car to the net. The warp and the weft were cut off by the straightening machine, vertical wire put by manual, the cross wire is fall from hopper.


2. Technical parameter



Model HY-DHW-1500 HY-DHW-2000 HY-DHW-2500 HY-DHW-2800 HY-DHW-3300
Weld width(mm) 1500 2000 2500 2800 3300
Meshi trip(mm) Single trip 3000 and no limit on return
Std trans.spacing >=25mm-stepless adjustable
Std long.spacing >=50mm, and progressive increase by 50 >=100mm, and increase by 100
Std weld spots 31 41 51 27 32
Wire diameter(mm) 3.0-6.0 3.0-6.0 3.0-6.0 5.0-12.0 5.0-12.0
Weld speed(times/min 50-70 40-60 40-60 40-60 40-60
Trans material Straight bar/rod Straight bar
Long material Straight bar/rod
Control mode PLC programming servo motor stepper
Mesh diagonal error <=2
Mesh overall error <=2
Air pressure >=0.7
Weld material Cold drawn wire, galvanized wire, cold rolled ribbed steel


3. Application area

The automatic PLC touch screen pneumatic spot welding machine is widely used as welded wire mesh fence panel,school playground fence , 3D wire mesh fence, welded garden fence curve welded fence and construction mesh panels.

4. Advantages

a. With our company's patented threading device, artificial threading more convenient, save time and effort.


b. Using our patented cross wire fallen device, the device is compact, rational layout, reliable work.

c. This machine is compact in structure, easily to operate and with fully functions. It has lower cost, high efficiency, reliable working, low energy consumption advantages.

d. Welding part can easily switch, which greatly improves the service life of machinery, maximum reduce the cost.


e. The machine line automatic degree can be according to request. For the economical type, line wire and cross wire are pre straightened and cut to length. We are capable to produce fully automatic machine.

Huayang PLC Screen SS Spot Welding Machine 60times/Min Stainless Steel 0
