Product Details:
|
| Product Name: | Automatic Six Feet 380V Roll Mesh Drive Shaft Welding Machine | Mesh Roll Length: | About 100m |
|---|---|---|---|
| Electrodes: | Single Or Double Row | Power: | 5kw,10kw |
| Mesh Shape: | Square | Voltage: | 220V/380V/415V/440V |
| Welding Way: | Spot Welding | Application: | Building&Construction |
| Place Of Origin: | Hebei Province, Huanghua City | After-sales Service: | Free Spare Parts, Online Support, Video Technical Support |
| High Light: | 6feet automatic wire mesh welding machine,automatic wire mesh welding machine 380v,380v drive shaft welding machine |
||
1. Product description
Automatic Six Feet 380V Roll Mesh Drive Shaft Welding Machine is used for making wire mesh. The feature of the machine is saving materials and high capacity. The button switches to start and stop machine easily. The galvanized iron wire green roll mesh welding machine can be quick and easy roll extraction from the machine.
2. Technical parameter
| Model | Mesh width | Minimum mesh size (inch) | Wire diameter(mm) | Welding speed (rows/min) | Roll mesh length (m) | Other available mesh size (inch) |
| R- DHW | 6 feet | 1/2x1/2 | 0.45-0.85 | 90-120 | 130 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6 feet | 1/2x1/2 | 0.6-1.3 | 90-120 | 110 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6 feet | 1/2x1/2 | 0.8-1.6 | 80-90 | 100 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6 feet | 1x1 | 0.45-0.85 | 90-120 | 130 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6 feet | 1x1 | 0.6-1.3 | 90-110 | 110 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6 feet | 1x1 | 0.8-1.6 |
90-110 |
100 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6 feet | 1x1 | 1.4-2.6 | 80-90 | 80 | 1x2, 2x1, 2x2, 2x4 |
3. Application area
Automatic Six Feet 380V Roll Mesh Drive Shaft Welding Machine is widely used in prevention for road, railway, airport, residence district, seaport, garden, feeding and husbandry.
4. Advantages
a. To increase safety of machine, we protect every transmission part(chain,rotate)with protective cover,and add switch in the electric cabinet.
b. To strengthen easy operation of machine,we use proximity switch between upper and lower welding heads,when cross wire doesn't reach,the machine will stop automatically.
c. Namely one worker can both operate wire mesh welding machine and repairing wire mesh,thus greatly improve the work efficiency and save labor.
