Synchronous 380v Diamond Mesh Wire Making Machine 70times/Min Galvanized Wire

Synchronous 380v Diamond Mesh Wire Making Machine 70times/Min Galvanized Wire
Synchronous 380v Diamond Mesh Wire Making Machine 70times/Min Galvanized Wire

Large Image :  Synchronous 380v Diamond Mesh Wire Making Machine 70times/Min Galvanized Wire

Product Details:
Place of Origin: China
Brand Name: Huayang
Certification: CE
Model Number: R-DHW
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: 1.Machine will be covered with plastic film and fastened by steel wire in container. 2. Spare parts will be packed into carton box and fastened stable in container.
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 20 sets/month

Synchronous 380v Diamond Mesh Wire Making Machine 70times/Min Galvanized Wire

Description
Product Name: Automatic Galvanized Wire Diamond Mesh Wire Making Machine Rated Capacity: 1 Year
Trademark: Huayang Feature: Automatic Wire Feeding
Color Of Machine: As Your Request Wire Diameter: 3.0-8.0mm
Mesh Size: 100-300mm Panel Mesh Dimension: 4000x2500mm
Welding Speed: 30-70 Times/min Nominal Voltage: 380v Or Customized
High Light:

Synchronous Diamond Mesh Wire Making Machine

,

380v Diamond Mesh Wire Making Machine

,

synchronous wire mesh welder

Automatic Galvanized Wire Diamond Mesh Wire Making Machine

1. Product description

Automatic galvanized wire diamond mesh wire making machine is used for making wire mesh. Using mechanical and electronic synchronous control technique separate welding mesh size, high precision, mesh can be adjusted within a certain range mainly used for farming(cages,rabbit cage,fox cage,etc.)Welding wire diameter:1.4-2.8mm, welding mesh:50x50-200x200mm,welding with:1220mm, welding speed:60times/min, rated voltage:380v 3-phase 50HZ,overall dimensions:2500x2700x1500,weight:2600kg.

2. Technical parameter


ModelHY-DHW-1500HY-DHW-2000HY-DHW-2500HY-DHW-2800HY-DHW-3300
Weld width(mm)15002000250028003300
Meshi trip(mm)Single trip 3000 and no limit on return
Std trans.spacing>=25mm-stepless adjustable
Std long.spacing>=50mm, and progressive increase by 50>=100mm, and increase by 100
Std weld spots3141512732
Wire diameter(mm)3.0-6.03.0-6.03.0-6.05.0-12.05.0-12.0
Weld speed(times/min50-7040-6040-6040-6040-60
Trans materialStraight bar/rodStraight bar
Long materialStraight bar/rod
Control modePLC programming servo motor stepper
Mesh diagonal error<=2
Mesh overall error<=2
Air pressure>=0.7
Weld materialCold drawn wire, galvanized wire, cold rolled ribbed steel


3. Application area

The automatic galvanized wire diamond mesh wire making machine can be used in coal mine roadway, concrete pavement, bridge deck, airport runway and construction.

4. Advantages

a. All the pneumatic components used are with world famous brand. For European customers, it is very easy to get the parts locally.

b. PLC controlled. Easy to set and control. It makes this machine more intelligent and reasonable.

c. The greatest advantage is possible to adjust the distance of line wires at random on the same mesh panel.

d. The welding wire diameter is able to be made to orders. The range of our mesh welding machine is from 0.3mm to 12mm. Material can be stainless steel wire, galvanized wire, plain steel bar, cold rolled rebar, hot rolled rebar.

e. The machine line automatic degree can be according to request. For the economical type, line wire and cross wire are pre straightened and cut to length. We are capable to produce fully automatic machine.
