Product Details:
|
| Product Name: | Wire Diameter 4mm Diamond Mesh Wire Making Machine | Welding Speed: | 70-90 Times/min |
|---|---|---|---|
| Trademark: | Huayang | Mesh Width: | 2500-3000mm |
| Overall Dimension: | 3400x1900x1500mm | Wire Diameter: | 3.0-8.0mm |
| Weight: | 4.2T | Application: | Panel Welding |
| Mesh Type: | Sheet, Panel | Nominal Voltage: | 380v Or Customized |
| High Light: | Dia 4mm Diamond Mesh Wire Making Machine,Huayang Diamond Mesh Wire Making Machine,90times/min Automated Welding Machine |
||
1. Product description
Wire diameter 4mm diamond mesh wire making machine is used for making wire mesh. We currently utilize seven fully automated CNC grid welding machines and two CNC jig welders that allow us to produce to your exact specifications. Sheet sizes can be up to 78” wide and 240” long (dependent on mesh spacing). Wire spacing and diameter configurations are nearly endless, allowing us to be the top manufacturing partner for custom welded wire mesh.
2. Technical parameter
| Model | HY-DHW-1500 | HY-DHW-2000 | HY-DHW-2500 | HY-DHW-2800 | HY-DHW-3300 |
| Weld width(mm) | 1500 | 2000 | 2500 | 2800 | 3300 |
| Meshi trip(mm) | Single trip 3000 and no limit on return | ||||
| Std trans.spacing | >=25mm-stepless adjustable | ||||
| Std long.spacing | >=50mm, and progressive increase by 50 | >=100mm, and increase by 100 | |||
| Std weld spots | 31 | 41 | 51 | 27 | 32 |
| Wire diameter(mm) | 3.0-6.0 | 3.0-6.0 | 3.0-6.0 | 5.0-12.0 | 5.0-12.0 |
| Weld speed(times/min | 50-70 | 40-60 | 40-60 | 40-60 | 40-60 |
| Trans material | Straight bar/rod | Straight bar | |||
| Long material | Straight bar/rod | ||||
| Control mode | PLC programming servo motor stepper | ||||
| Mesh diagonal error | <=2 | ||||
| Mesh overall error | <=2 | ||||
| Air pressure | >=0.7 | ||||
| Weld material | Cold drawn wire, galvanized wire, cold rolled ribbed steel | ||||
3. Application area
The wire diameter 4mm diamond mesh wire making machine can be used to make wall mesh, concrete mesh, construction mesh, breed cage etc.
4. Advantages
a. The welding part of wire mesh welding machine is used the springiness input wire trunking that makes the welding copper use for long time.
b. Mesh pulling cart with railway 6m, max mesh weight 60kg.
c. Cross wire hopper with loading capacity 100kg.
d. This wire mesh welding machine adopts synchronous control technique. The cent-control and welding time are composed of PLC program system. The input front-panel is touch screen , the operate is more intelligent and reasonable.
e. The machine line automatic degree can be according to request. For the economical type, line wire and cross wire are pre straightened and cut to length. We are capable to produce fully automatic machine.
